Juniper vMX – Inter-AS BGP L2VPN Option B

nick Leave a comment

Slight difference to Option A topology. Still running Segment Routing in AS65200 but AS65400 is now running RSVP. Great article linked below from Chris Parker who explains Option B in more detail (click on Network Fun Times link). OSPF configured on the 2 Cisco CE devices.

Network Fun Times Inter-AS Option B

_Exports_eve-ng_export-20241110-130119Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 vlan-tagging
set interfaces ge-0/0/0 encapsulation flexible-ethernet-services
set interfaces ge-0/0/0 unit 123 encapsulation vlan-ccc
set interfaces ge-0/0/0 unit 123 vlan-id 123
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/2.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 5.5.5.5
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 20
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L2VPN instance-type l2vpn
set routing-instances L2VPN interface ge-0/0/0.123
set routing-instances L2VPN route-distinguisher 5.5.5.5:123
set routing-instances L2VPN vrf-target target:65200:123
set routing-instances L2VPN protocols l2vpn encapsulation-type ethernet-vlan
set routing-instances L2VPN protocols l2vpn site L2VPN site-identifier 1
set routing-instances L2VPN protocols l2vpn site L2VPN interface ge-0/0/0.123

P1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 6.6.6.6
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL cluster 6.6.6.6
set protocols bgp group INTERNAL neighbor 5.5.5.5
set protocols bgp group INTERNAL neighbor 33.33.33.33
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 25
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

ASBR1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 10.33.33.1/30
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 33.33.33.33/32
set interfaces lo0 unit 0 family iso address 49.0000.3333.3333.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 33.33.33.33
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols mpls interface ge-0/0/1.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 33.33.33.33
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols bgp group AS65400 type external
set protocols bgp group AS65400 family l2vpn signaling
set protocols bgp group AS65400 peer-as 65400
set protocols bgp group AS65400 neighbor 10.33.33.2
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 30
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

ASBR2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 10.33.33.2/30
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.7777.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set routing-options resolution
set protocols rsvp interface ge-0/0/1.0
set protocols rsvp interface lo0.0
set protocols mpls label-switched-path PE2 to 8.8.8.8
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols mpls interface ge-0/0/0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 7.7.7.7
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols bgp group AS65200 type external
set protocols bgp group AS65200 family l2vpn signaling
set protocols bgp group AS65200 peer-as 65200
set protocols bgp group AS65200 neighbor 10.33.33.1
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

P2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 5.5.5.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces fxp0 unit 0 family inet dhcp vendor-id Juniper-vmx-VM67309BAAF3
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.9999.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set routing-options resolution rib bgp.l2vpn.0 resolution-ribs inet.0
set protocols rsvp interface ge-0/0/0.0
set protocols rsvp interface ge-0/0/1.0
set protocols rsvp interface lo0.0
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 9.9.9.9
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL cluster 9.9.9.9
set protocols bgp group INTERNAL neighbor 7.7.7.7
set protocols bgp group INTERNAL neighbor 8.8.8.8
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 5.5.5.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 vlan-tagging
set interfaces ge-0/0/1 encapsulation flexible-ethernet-services
set interfaces ge-0/0/1 unit 123 encapsulation vlan-ccc
set interfaces ge-0/0/1 unit 123 vlan-id 123
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.8888.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols rsvp interface ge-0/0/0.0
set protocols rsvp interface lo0.0
set protocols mpls label-switched-path ASBR2 to 7.7.7.7
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 8.8.8.8
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L2VPN instance-type l2vpn
set routing-instances L2VPN interface ge-0/0/1.123
set routing-instances L2VPN route-distinguisher 8.8.8.8:123
set routing-instances L2VPN vrf-target target:65200:123
set routing-instances L2VPN protocols l2vpn encapsulation-type ethernet-vlan
set routing-instances L2VPN protocols l2vpn site L2VPN site-identifier 2
set routing-instances L2VPN protocols l2vpn site L2VPN interface ge-0/0/1.123

OSPF is now up on the 2 Cisco CE devices, confirming the layer 2 VPN is established.

Juniper vMX – Inter-AS L3VPN Option A

nick Leave a comment

This topology uses option A and, as usual, 2 Cisco devices as CEs. BGP is used for routing between PEs & CEs. AS65200 is running Segment Routing and AS65400 LDP.

https://www.juniper.net/documentation/us/en/software/junos/vpn-l3/topics/topic-map/l3-vpns-interprovider.html#:~:text=Interprovider%20Layer%203%20VPN%20Option%20A%20provides%20interprovider%20VRF%2Dto,is%20the%20least%20scalable%20solution.

_Exports_eve-ng_export-20241109-220516Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 10.1.1.1/24
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/2.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 5.5.5.5
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 20
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L3VPN instance-type vrf
set routing-instances L3VPN interface ge-0/0/0.0
set routing-instances L3VPN route-distinguisher 5.5.5.5:1
set routing-instances L3VPN vrf-target target:65200:1
set routing-instances L3VPN vrf-table-label
set routing-instances L3VPN protocols bgp group L3VPN type external
set routing-instances L3VPN protocols bgp group L3VPN as-override
set routing-instances L3VPN protocols bgp group L3VPN neighbor 10.1.1.254 peer-as 65444

P1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 6.6.6.6
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL cluster 6.6.6.6
set protocols bgp group INTERNAL neighbor 5.5.5.5
set protocols bgp group INTERNAL neighbor 33.33.33.33
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 25
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

ASBR1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 10.33.33.1/30
set interfaces lo0 unit 0 family inet address 33.33.33.33/32
set interfaces lo0 unit 0 family iso address 49.0000.3333.3333.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 33.33.33.33
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 33.33.33.33
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 30
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L3VPN instance-type vrf
set routing-instances L3VPN interface ge-0/0/1.0
set routing-instances L3VPN route-distinguisher 33.33.33.33:1
set routing-instances L3VPN vrf-target target:65200:1
set routing-instances L3VPN protocols bgp group AS65400 type external
set routing-instances L3VPN protocols bgp group AS65400 neighbor 10.33.33.2 peer-as 65400

ASBR2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 10.33.33.2/30
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.7777.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 7.7.7.7
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/1.0
set protocols ldp interface lo0.0
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L3VPN instance-type vrf
set routing-instances L3VPN interface ge-0/0/0.0
set routing-instances L3VPN route-distinguisher 7.7.7.7:1
set routing-instances L3VPN vrf-target target:65200:1
set routing-instances L3VPN protocols bgp group AS65200 type external
set routing-instances L3VPN protocols bgp group AS65200 neighbor 10.33.33.1 peer-as 65200

P2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 5.5.5.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.9999.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 9.9.9.9
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL cluster 9.9.9.9
set protocols bgp group INTERNAL neighbor 7.7.7.7
set protocols bgp group INTERNAL neighbor 8.8.8.8
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/0.0
set protocols ldp interface ge-0/0/1.0
set protocols ldp interface lo0.0
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 5.5.5.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 11.1.1.1/24
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.8888.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 8.8.8.8
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/0.0
set protocols ldp interface lo0.0
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L3VPN instance-type vrf
set routing-instances L3VPN interface ge-0/0/1.0
set routing-instances L3VPN route-distinguisher 8.8.8.8:1
set routing-instances L3VPN vrf-target target:65200:1
set routing-instances L3VPN vrf-table-label
set routing-instances L3VPN protocols bgp group L3VPN type external
set routing-instances L3VPN protocols bgp group L3VPN as-override
set routing-instances L3VPN protocols bgp group L3VPN neighbor 11.1.1.254 peer-as 65444

The 2 CE devices will now have IP connectivity and you can see the respective routes have been learnt on both sides.

Juniper vMX – Carrier of Carriers EVPN VPLS

nick Leave a comment

This lab is slightly different to the other Carrier of Carrier lab where LDP was used in each AS. In this lab, AS65200 is using LDP, AS65400 RSVP & AS65600 Segment Routing. 2 Cisco vIOS devices used as CE devices

https://www.juniper.net/documentation/us/en/software/junos/vpn-l3/topics/topic-map/l3-vpns-carrier-carrier.html

_Exports_eve-ng_export-20241109-101638Download

PE1

set interfaces ge-0/0/0 vlan-tagging
set interfaces ge-0/0/0 encapsulation vlan-vpls
set interfaces ge-0/0/0 unit 909 encapsulation vlan-vpls
set interfaces ge-0/0/0 unit 909 vlan-id 909
set interfaces ge-0/0/0 unit 909 family vpls
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/2.0
set protocols mpls interface lo0.0
set protocols bgp group AS65600 type external
set protocols bgp group AS65600 multihop
set protocols bgp group AS65600 local-address 5.5.5.5
set protocols bgp group AS65600 family evpn signaling
set protocols bgp group AS65600 peer-as 65600
set protocols bgp group AS65600 neighbor 11.11.11.11
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 5.5.5.5
set protocols bgp group INTERNAL family inet labeled-unicast resolve-vpn
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/2.0
set protocols ldp interface lo0.0
set routing-instances vpls instance-type evpn
set routing-instances vpls interface ge-0/0/0.909
set routing-instances vpls route-distinguisher 5.5.5.5:909
set routing-instances vpls vrf-target target:65200:909
set routing-instances vpls protocols vpls site-range 1000
set routing-instances vpls protocols vpls no-tunnel-services
set routing-instances vpls protocols vpls site vpls-1 site-identifier 1
set routing-instances vpls protocols vpls site vpls-1 interface ge-0/0/0.909
set routing-instances vpls protocols evpn interface ge-0/0/0.909

ASBR1

set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 6.6.6.6
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL neighbor 5.5.5.5
set protocols bgp group AS65400 type external
set protocols bgp group AS65400 family inet labeled-unicast
set protocols bgp group AS65400 export PE1_LOOPBACK
set protocols bgp group AS65400 peer-as 65400
set protocols bgp group AS65400 neighbor 2.2.2.2
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/0.0
set protocols ldp interface lo0.0
set policy-options policy-statement PE1_LOOPBACK from route-filter 5.5.5.5/32 exact
set policy-options policy-statement PE1_LOOPBACK then accept

CoC ASBR1

set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols rsvp interface ge-0/0/1.0
set protocols rsvp interface lo0.0
set protocols mpls label-switched-path ASBR2 to 9.9.9.9
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group AS65200 type external
set protocols bgp group AS65200 family inet labeled-unicast
set protocols bgp group AS65200 peer-as 65200
set protocols bgp group AS65200 neighbor 2.2.2.1
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 7.7.7.7
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL neighbor 8.8.8.8
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive

CoC Core

set interfaces ge-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols rsvp interface ge-0/0/0.0
set protocols rsvp interface ge-0/0/1.0
set protocols rsvp interface lo0.0
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 8.8.8.8
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL cluster 8.8.8.8
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols bgp group INTERNAL neighbor 7.7.7.7
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive

CoC ASBR2

set interfaces ge-0/0/0 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 5.5.5.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.9999.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set protocols rsvp interface ge-0/0/0.0
set protocols rsvp interface lo0.0
set protocols mpls label-switched-path ASBR1 to 7.7.7.7
set protocols mpls interface ge-0/0/0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 9.9.9.9
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL neighbor 8.8.8.8
set protocols bgp group AS65600 type external
set protocols bgp group AS65600 family inet labeled-unicast
set protocols bgp group AS65600 peer-as 65600
set protocols bgp group AS65600 neighbor 5.5.5.2
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive

ASBR2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 5.5.5.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 6.6.6.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 10.10.10.10/32
set interfaces lo0 unit 0 family iso address 49.0000.1010.1010.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 10.10.10.10
set routing-options autonomous-system 65600
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 10.10.10.10
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL neighbor 11.11.11.11
set protocols bgp group AS65400 type external
set protocols bgp group AS65400 family inet labeled-unicast
set protocols bgp group AS65400 export PE2_LOOPBACK
set protocols bgp group AS65400 peer-as 65400
set protocols bgp group AS65400 neighbor 5.5.5.1
set protocols isis source-packet-routing srgb start-label 55000
set protocols isis source-packet-routing srgb index-range 10000
set protocols isis source-packet-routing node-segment ipv4-index 1000
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement PE2_LOOPBACK from route-filter 11.11.11.11/32 exact
set policy-options policy-statement PE2_LOOPBACK then accept

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 6.6.6.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 vlan-tagging
set interfaces ge-0/0/1 encapsulation vlan-vpls
set interfaces ge-0/0/1 unit 909 encapsulation vlan-vpls
set interfaces ge-0/0/1 unit 909 vlan-id 909
set interfaces ge-0/0/1 unit 909 family vpls
set interfaces lo0 unit 0 family inet address 11.11.11.11/32
set interfaces lo0 unit 0 family iso address 49.0000.1111.1111.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 11.11.11.11
set routing-options autonomous-system 65600
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 11.11.11.11
set protocols bgp group INTERNAL family inet labeled-unicast resolve-vpn
set protocols bgp group INTERNAL neighbor 10.10.10.10
set protocols bgp group AS65200 multihop
set protocols bgp group AS65200 local-address 11.11.11.11
set protocols bgp group AS65200 family evpn signaling
set protocols bgp group AS65200 peer-as 65200
set protocols bgp group AS65200 neighbor 5.5.5.5
set protocols isis source-packet-routing srgb start-label 55000
set protocols isis source-packet-routing srgb index-range 10000
set protocols isis source-packet-routing node-segment ipv4-index 1100
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set routing-instances vpls instance-type evpn
set routing-instances vpls interface ge-0/0/1.909
set routing-instances vpls route-distinguisher 11.11.11.11:909
set routing-instances vpls vrf-target target:65200:909
set routing-instances vpls protocols vpls site-range 1000
set routing-instances vpls protocols vpls no-tunnel-services
set routing-instances vpls protocols vpls site vpls-1 site-identifier 1
set routing-instances vpls protocols vpls site vpls-1 interface ge-0/0/1.909
set routing-instances vpls protocols evpn interface ge-0/0/1.909

The VPLS circuit will now be up and OSPF has been configured to the 2 Cisco CE devices to confirm this.

Juniper vMX – IPv6 Tunneling over SR

nick Leave a comment

Quite a simple lab this one. A customer wants to establish IPv6 connectivity between 2 sites over our SR IPv4 core so IPv6 tunneling is required. 2 Cisco vIOS routers used as the CE devices.

https://www.juniper.net/documentation/us/en/software/junos/mpls/topics/topic-map/ipv6-o-ipv4-tunnels.html

_Exports_eve-ng_export-20241103-120152Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family inet6
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet6 address 2a45:0425:2ca1::0567:5673:23b4/127
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.0000.0000.00
set interfaces lo0 unit 0 family mpls
set policy-options policy-statement BGPv6 from family inet6
set policy-options policy-statement BGPv6 from protocol bgp
set policy-options policy-statement BGPv6 then accept
set policy-options policy-statement V6 from family inet6
set policy-options policy-statement V6 from protocol bgp
set policy-options policy-statement V6 from protocol direct
set policy-options policy-statement V6 then accept
set policy-options policy-statement next-hop-self then next-hop self
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65400
set protocols bgp group CE1 type external
set protocols bgp group CE1 local-address 2a45:0425:2ca1::0567:5673:23b4
set protocols bgp group CE1 family inet6 unicast
set protocols bgp group CE1 export BGPv6
set protocols bgp group CE1 peer-as 65001
set protocols bgp group CE1 neighbor 2a45:0425:2ca1::0567:5673:23b5
set protocols bgp group V6TUNNEL type internal
set protocols bgp group V6TUNNEL local-address 5.5.5.5
set protocols bgp group V6TUNNEL family inet6 labeled-unicast explicit-null
set protocols bgp group V6TUNNEL export next-hop-self
set protocols bgp group V6TUNNEL export V6
set protocols bgp group V6TUNNEL neighbor 7.7.7.7
set protocols isis source-packet-routing srgb start-label 30000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 100
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols mpls ipv6-tunneling
set protocols mpls interface ge-0/0/0.0

P1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family inet6
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.1.1.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family inet6
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.0000.0000.00
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65400
set protocols isis source-packet-routing srgb start-label 30000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 200
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family inet6
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet6 address 2ab5:0425:2ca1::0567:5673:23b4/127
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.0000.0000.00
set interfaces lo0 unit 0 family mpls
set policy-options policy-statement BGPv6 from family inet6
set policy-options policy-statement BGPv6 from protocol bgp
set policy-options policy-statement BGPv6 then accept
set policy-options policy-statement V6 from family inet6
set policy-options policy-statement V6 from protocol bgp
set policy-options policy-statement V6 from protocol direct
set policy-options policy-statement V6 then accept
set policy-options policy-statement next-hop-self then next-hop self
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols bgp group CE1 type external
set protocols bgp group CE1 local-address 2ab5:0425:2ca1::0567:5673:23b4
set protocols bgp group CE1 family inet6 unicast
set protocols bgp group CE1 export BGPv6
set protocols bgp group CE1 peer-as 65003
set protocols bgp group CE1 neighbor 2ab5:0425:2ca1::0567:5673:23b5
set protocols bgp group V6TUNNEL type internal
set protocols bgp group V6TUNNEL local-address 7.7.7.7
set protocols bgp group V6TUNNEL family inet6 labeled-unicast explicit-null
set protocols bgp group V6TUNNEL export next-hop-self
set protocols bgp group V6TUNNEL export V6
set protocols bgp group V6TUNNEL neighbor 5.5.5.5
set protocols isis source-packet-routing srgb start-label 30000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 300
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols mpls ipv6-tunneling
set protocols mpls interface ge-0/0/0.0

Routes are now being learned from the other CE device and IPv6 connectivity is up between the 2 sites.

Juniper vMX – RSVP EVPN VPLS

nick Leave a comment

A change with this lab as RSVP will be used as the MPLS signalling protocol. IS-IS for the IGP and Cisco vIOS again used as the CE devices

https://community.juniper.net/blogs/ramdas-machat/2022/11/01/vpls-to-evpn-vpls-seamless-migration-on-mx-routers

Exports_eve-ng_export-20240602-184139Download

PE1

set interfaces ge-0/0/0 vlan-tagging
set interfaces ge-0/0/0 encapsulation vlan-vpls
set interfaces ge-0/0/0 unit 3333 encapsulation vlan-vpls
set interfaces ge-0/0/0 unit 3333 vlan-id 3333
set interfaces ge-0/0/0 unit 3333 family vpls
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65400
set protocols rsvp interface all
set protocols mpls label-switched-path TO_PE2 to 8.8.8.8
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 5.5.5.5
set protocols bgp group internal family l2vpn signaling
set protocols bgp group internal family evpn signaling
set protocols bgp group internal neighbor 8.8.8.8
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0
set routing-instances vpls instance-type evpn
set routing-instances vpls interface ge-0/0/0.3333
set routing-instances vpls route-distinguisher 5.5.5.5:1
set routing-instances vpls vrf-target target:65530:1
set routing-instances vpls protocols vpls site-range 1000
set routing-instances vpls protocols vpls no-tunnel-services
set routing-instances vpls protocols vpls site vpls-1 site-identifier 1
set routing-instances vpls protocols vpls site vpls-1 interface ge-0/0/0.3333
set routing-instances vpls protocols evpn interface ge-0/0/0.3333

P1

set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set protocols rsvp interface all
set protocols mpls interface all
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0

P2

set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 33.33.33.33/32
set interfaces lo0 unit 0 family iso address 49.0000.3333.3333.0000.00
set interfaces lo0 unit 0 family mpls
set protocols rsvp interface all
set protocols mpls interface all
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0

P3

set interfaces ge-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.7777.00
set interfaces lo0 unit 0 family mpls
set protocols rsvp interface all
set protocols mpls interface all
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0

PE2

set interfaces ge-0/0/0 vlan-tagging
set interfaces ge-0/0/0 encapsulation vlan-vpls
set interfaces ge-0/0/0 unit 3333 encapsulation vlan-vpls
set interfaces ge-0/0/0 unit 3333 vlan-id 3333
set interfaces ge-0/0/0 unit 3333 family vpls
set interfaces ge-0/0/2 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.8888.00
set interfaces lo0 unit 0 family mpls
set routing-options autonomous-system 65400
set protocols rsvp interface all
set protocols mpls label-switched-path TO_PE1 to 5.5.5.5
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 8.8.8.8
set protocols bgp group internal family l2vpn signaling
set protocols bgp group internal family evpn signaling
set protocols bgp group internal neighbor 5.5.5.5
set protocols isis level 1 disable
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0
set routing-instances vpls instance-type evpn
set routing-instances vpls interface ge-0/0/0.3333
set routing-instances vpls route-distinguisher 8.8.8.8:1
set routing-instances vpls vrf-target target:65530:1
set routing-instances vpls protocols vpls site-range 1000
set routing-instances vpls protocols vpls no-tunnel-services
set routing-instances vpls protocols vpls site vpls-2 site-identifier 2
set routing-instances vpls protocols vpls site vpls-2 interface ge-0/0/0.3333
set routing-instances vpls protocols evpn interface ge-0/0/0.3333

The VPLS circuit will now be up.

OSPF has been configured to the Cisco devices but you could chose another protocol if you prefer.

Juniper vMX – EVPN VPWS

nick Leave a comment

Cisco vIOS switches used as the CE devices and a LAG between them and the PE vMX’s. IS-IS for the underlay and LDP for the label distribution. You could use RSVP or Segment Routing if you prefer.

https://www.juniper.net/documentation/us/en/software/junos/evpn-vxlan/topics/example/example-configuring-vpws-service-with-evpn-signaling-mechanisms.html

Exports_eve-ng_export-20240506-101311Download

PE1

set chassis aggregated-devices ethernet device-count 1
set interfaces ge-0/0/0 gigether-options 802.3ad ae0
set interfaces ge-0/0/1 gigether-options 802.3ad ae0
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces ae0 flexible-vlan-tagging
set interfaces ae0 encapsulation flexible-ethernet-services
set interfaces ae0 aggregated-ether-options lacp active
set interfaces ae0 unit 444 encapsulation vlan-ccc
set interfaces ae0 unit 444 vlan-id 444
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65400
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 5.5.5.5
set protocols bgp group internal family evpn signaling
set protocols bgp group internal neighbor 8.8.8.8
set protocols isis level 1 disable
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0
set protocols ldp interface all
set routing-instances customer1 instance-type evpn-vpws
set routing-instances customer1 interface ae0.444
set routing-instances customer1 route-distinguisher 5.5.5.5:1
set routing-instances customer1 vrf-target target:65400:1
set routing-instances customer1 protocols evpn interface ae0.444 vpws-service-id local 22
set routing-instances customer1 protocols evpn interface ae0.444 vpws-service-id remote 44

P1

set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set protocols mpls interface all
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0
set protocols ldp interface all

P2

set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 33.33.33.33/32
set interfaces lo0 unit 0 family iso address 49.0000.3333.3333.0000.00
set interfaces lo0 unit 0 family mpls
set protocols mpls interface all
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0
set protocols ldp interface all

P3

set interfaces ge-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.7777.00
set interfaces lo0 unit 0 family mpls
set protocols mpls interface all
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0
set protocols ldp interface all

PE2

set chassis aggregated-devices ethernet device-count 1
set interfaces ge-0/0/0 gigether-options 802.3ad ae0
set interfaces ge-0/0/1 gigether-options 802.3ad ae0
set interfaces ge-0/0/2 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces ae0 flexible-vlan-tagging
set interfaces ae0 encapsulation flexible-ethernet-services
set interfaces ae0 aggregated-ether-options lacp active
set interfaces ae0 unit 444 encapsulation vlan-ccc
set interfaces ae0 unit 444 vlan-id 444
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.8888.00
set interfaces lo0 unit 0 family mpls
set routing-options autonomous-system 65400
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 8.8.8.8
set protocols bgp group internal family evpn signaling
set protocols bgp group internal neighbor 5.5.5.5
set protocols isis level 1 disable
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0
set protocols ldp interface all
set routing-instances customer1 instance-type evpn-vpws
set routing-instances customer1 interface ae0.444
set routing-instances customer1 route-distinguisher 8.8.8.8:1
set routing-instances customer1 vrf-target target:65400:1
set routing-instances customer1 protocols evpn interface ae0.444 vpws-service-id local 44
set routing-instances customer1 protocols evpn interface ae0.444 vpws-service-id remote 22

VPWS instance will now be up. OSPF has been configured on both CE devices and relatiionship is up

Juniper vMX – Segment Routing L3VPN

nick Leave a comment

You will need a trial license from Juniper for this lab, which can be obtained from the below URL.

https://www.juniper.net/gb/en/dm/vmx-trial-download.html

BGP is used between the CE & PE devices. Could use OSPF but would then need a sham link between CE devices to stop routes being shown as external routes.

https://www.juniper.net/gb/en/research-topics/what-is-segment-routing.html

Exports_eve-ng_export-20240505-163439Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 10.1.1.1/24
set interfaces ge-0/0/1 unit 0 family inet
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65400
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 5.5.5.5
set protocols bgp group internal family inet unicast
set protocols bgp group internal family inet-vpn unicast
set protocols bgp group internal neighbor 8.8.8.8
set protocols isis source-packet-routing srgb start-label 800000
set protocols isis source-packet-routing srgb index-range 9000
set protocols isis source-packet-routing node-segment ipv4-index 500
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0
set routing-instances cust1 instance-type vrf
set routing-instances cust1 interface ge-0/0/0.0
set routing-instances cust1 route-distinguisher 5.5.5.5:1
set routing-instances cust1 vrf-target target:65400:1
set routing-instances cust1 vrf-table-label
set routing-instances cust1 protocols bgp group cust1 type external
set routing-instances cust1 protocols bgp group cust1 as-override
set routing-instances cust1 protocols bgp group cust1 neighbor 10.1.1.254 peer-as 65444

P1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set protocols mpls interface all
set protocols isis source-packet-routing srgb start-label 800000
set protocols isis source-packet-routing srgb index-range 9000
set protocols isis source-packet-routing node-segment ipv4-index 501
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0

P2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 33.33.33.33/32
set interfaces lo0 unit 0 family iso address 49.0000.3333.3333.0000.00
set interfaces lo0 unit 0 family mpls
set protocols mpls interface all
set protocols isis source-packet-routing srgb start-label 800000
set protocols isis source-packet-routing srgb index-range 9000
set protocols isis source-packet-routing node-segment ipv4-index 502
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0

P3

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.7777.00
set interfaces lo0 unit 0 family mpls
set protocols mpls interface all
set protocols isis source-packet-routing srgb start-label 800000
set protocols isis source-packet-routing srgb index-range 9000
set protocols isis source-packet-routing node-segment ipv4-index 503
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 10.10.10.1/24
set interfaces ge-0/0/2 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.8888.00
set interfaces lo0 unit 0 family mpls
set routing-options autonomous-system 65400
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 8.8.8.8
set protocols bgp group internal family inet unicast
set protocols bgp group internal family inet-vpn unicast
set protocols bgp group internal neighbor 5.5.5.5
set protocols isis source-packet-routing srgb start-label 800000
set protocols isis source-packet-routing srgb index-range 9000
set protocols isis source-packet-routing node-segment ipv4-index 504
set protocols isis level 1 disable
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0
set routing-instances cust1 instance-type vrf
set routing-instances cust1 interface ge-0/0/0.0
set routing-instances cust1 route-distinguisher 8.8.8.8:1
set routing-instances cust1 vrf-target target:65400:1
set routing-instances cust1 vrf-table-label
set routing-instances cust1 protocols bgp group cust1 type external
set routing-instances cust1 protocols bgp group cust1 as-override
set routing-instances cust1 protocols bgp group cust1 neighbor 10.10.10.254 peer-as 65444

The L3VPN will now be up and the CE devices receiving routes from each other. You may need to reboot the vMX devices before you see the routes.

Cisco IOS XE – MPLS EVPN

nick Leave a comment

IS-IS is used for the underlay. The 2 CEs are Cisco vIOS switches with VLAN 2222 and OSPF configured on them.

https://www.cisco.com/c/en/us/td/docs/routers/ios/config/17-x/mpls/b-mpls/m-evpn-over-mpls.html

Exports_eve-ng_export-20240421-092529Download

PE1

hostname pe1

mpls label protocol ldp
l2vpn evpn
replication-type ingress
mpls label mode per-ce
router-id Loopback0

l2vpn evpn instance 1 vlan-based
route-target export 65200:1
route-target import 65200:1
no auto-route-target

bridge-domain 1
member GigabitEthernet2 service-instance 1
member evpn-instance 1

interface Loopback0
ip address 5.5.5.5 255.255.255.255
ip router isis 1

interface GigabitEthernet1
ip address 1.1.1.1 255.255.255.252
ip router isis 1
mpls ip

interface GigabitEthernet2
no ip address
service instance 1 ethernet
encapsulation dot1q 2222

router isis 1
net 49.0000.5555.5555.5555.00

router bgp 65200
bgp router-id 5.5.5.5
bgp log-neighbor-changes
neighbor 9.9.9.9 remote-as 65200
neighbor 9.9.9.9 update-source Loopback0

address-family ipv4
neighbor 9.9.9.9 activate
exit-address-family

address-family l2vpn evpn
neighbor 9.9.9.9 activate
neighbor 9.9.9.9 send-community both
exit-address-family

P1

hostname p1

mpls label protocol ldp

interface Loopback0
ip address 6.6.6.6 255.255.255.255
ip router isis 1

interface GigabitEthernet1
ip address 1.1.1.2 255.255.255.252
ip router isis 1
mpls ip

interface GigabitEthernet2
ip address 2.2.2.1 255.255.255.252
ip router isis 1
mpls ip

router isis 1
net 49.0000.6666.6666.6666.00

P2

hostname p2

mpls label protocol ldp

interface Loopback0
ip address 7.7.7.7 255.255.255.255
ip router isis 1

interface GigabitEthernet1
ip address 2.2.2.2 255.255.255.252
ip router isis 1
mpls ip

interface GigabitEthernet2
ip address 3.3.3.1 255.255.255.252
ip router isis 1
mpls ip

router isis 1
net 49.0000.7777.7777.7777.00

P3

hostname p3

mpls label protocol ldp

interface Loopback0
ip address 8.8.8.8 255.255.255.255
ip router isis 1

interface GigabitEthernet1
ip address 3.3.3.2 255.255.255.252
ip router isis 1
mpls ip

interface GigabitEthernet2
ip address 4.4.4.1 255.255.255.252
ip router isis 1
mpls ip

router isis 1
net 49.0000.8888.8888.8888.00

PE2

hostname pe2

mpls label protocol ldp

l2vpn evpn
replication-type ingress
mpls label mode per-ce
router-id Loopback0

l2vpn evpn instance 1 vlan-based
route-target export 65200:1
route-target import 65200:1
no auto-route-target

bridge-domain 1
member GigabitEthernet2 service-instance 1
member evpn-instance 1

interface Loopback0
ip address 9.9.9.9 255.255.255.255
ip router isis 1

interface GigabitEthernet1
ip address 4.4.4.2 255.255.255.252
ip router isis 1
mpls ip

interface GigabitEthernet2
no ip address
service instance 1 ethernet
encapsulation dot1q 2222

router isis 1
net 49.0000.9999.9999.9999.00

router bgp 65200
bgp router-id 9.9.9.9
bgp log-neighbor-changes
neighbor 5.5.5.5 remote-as 65200
neighbor 5.5.5.5 update-source Loopback0

address-family ipv4
neighbor 5.5.5.5 activate
exit-address-family

address-family l2vpn evpn
neighbor 5.5.5.5 activate
neighbor 5.5.5.5 send-community both
exit-address-family

OSPF will now be up between the 2 CEs and MAC addresses being learnt on the 2 PE devices.

Arista – Segment Routing MPLS EVPN

nick Leave a comment

IS-IS used for the segment routing. 2 Cisco vIOS devices for the CE’s, with OSPF configured on each

https://www.arista.com/en/solutions/mpls-segment-routing

Exports_eve-ng_export-20240407-091304Download

PE1

service routing protocols model multi-agent

hostname pe1

vlan 3333

interface Ethernet1
switchport trunk allowed vlan 3333
switchport mode trunk

interface Ethernet2
no switchport
ip address 1.1.1.1/30
isis enable 1

interface Loopback0
ip address 5.5.5.5/32
node-segment ipv4 index 10
isis enable 1

ip routing

mpls ip

router bgp 65400
router-id 5.5.5.5
neighbor 9.9.9.9 remote-as 65400
neighbor 9.9.9.9 update-source Loopback0
neighbor 9.9.9.9 rib-in pre-policy retain all
neighbor 9.9.9.9 send-community extended

vlan-aware-bundle customer1
rd 5.5.5.5:1
route-target both 65400:1
redistribute learned
vlan 3333

address-family evpn
neighbor default encapsulation mpls next-hop-self source-interface Loopback0
neighbor 9.9.9.9 activate

router isis 1
net 49.0000.5555.5555.5555.00
is-type level-2
segment-routing mpls
no shutdown
address-family ipv4 unicast

P1

service routing protocols model multi-agent

hostname p1

interface Ethernet1
no switchport
ip address 1.1.1.2/30
isis enable 1

interface Ethernet2
no switchport
ip address 2.2.2.1/30
isis enable 1

interface Loopback0
ip address 6.6.6.6/32
node-segment ipv4 index 20
isis enable 1

ip routing

mpls ip

router isis 1
net 49.0000.6666.6666.6666.00
is-type level-2
segment-routing mpls
no shutdown
address-family ipv4 unicast

P2

service routing protocols model multi-agent

hostname p2

interface Ethernet1
no switchport
ip address 2.2.2.2/30
isis enable 1

interface Ethernet2
no switchport
ip address 3.3.3.1/30
isis enable 1

interface Loopback0
ip address 7.7.7.7/32
node-segment ipv4 index 30
isis enable 1

ip routing

mpls ip

router isis 1
net 49.0000.7777.7777.7777.00
is-type level-2
segment-routing mpls
no shutdown
address-family ipv4 unicast

P3

service routing protocols model multi-agent

hostname p3

interface Ethernet1
no switchport
ip address 3.3.3.2/30
isis enable 1

interface Ethernet2
no switchport
ip address 4.4.4.1/30
isis enable 1

interface Loopback0
ip address 8.8.8.8/32
node-segment ipv4 index 40
isis enable 1

ip routing

mpls ip

router isis 1
net 49.0000.8888.8888.8888.00
is-type level-2
segment-routing mpls
no shutdown
address-family ipv4 unicast

PE2

service routing protocols model multi-agent

hostname pe2

vlan 3333

interface Ethernet1
switchport trunk allowed vlan 3333
switchport mode trunk

interface Ethernet2
no switchport
ip address 4.4.4.2/30
isis enable 1

interface Loopback0
ip address 9.9.9.9/32
node-segment ipv4 index 50
isis enable 1

ip routing

mpls ip

router bgp 65400
router-id 9.9.9.9
neighbor 5.5.5.5 remote-as 65400
neighbor 5.5.5.5 update-source Loopback0
neighbor 5.5.5.5 rib-in pre-policy retain all
neighbor 5.5.5.5 send-community extended

vlan-aware-bundle customer1
rd 9.9.9.9:1
route-target both 65400:1
redistribute learned
vlan 3333

address-family evpn
neighbor default encapsulation mpls next-hop-self source-interface Loopback0
neighbor 5.5.5.5 activate

router isis 1
net 49.0000.9999.9999.9999.00
is-type level-2
segment-routing mpls
no shutdown
address-family ipv4 unicast

OSPF should now be up between the 2 CE devices.

Juniper Carrier of Carriers BGP L2VPN

nick Leave a comment

Establish a layer 2 circuit between the 2 CE devices, traversing 3 separate AS’s.

https://www.juniper.net/documentation/us/en/software/junos/vpn-l3/topics/topic-map/l3-vpns-carrier-carrier.html

Exports_eve-ng_export-20240315-171046Download

PE1

set interfaces ge-0/0/0 vlan-tagging
set interfaces ge-0/0/0 encapsulation flexible-ethernet-services
set interfaces ge-0/0/0 unit 3222 encapsulation vlan-ccc
set interfaces ge-0/0/0 unit 3222 vlan-id 3222
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65200
set protocols mpls interface all
set protocols bgp group external type external
set protocols bgp group external multihop
set protocols bgp group external local-address 5.5.5.5
set protocols bgp group external family l2vpn signaling
set protocols bgp group external peer-as 65600
set protocols bgp group external neighbor 11.11.11.11
set protocols bgp group internal type internal
set protocols bgp group internal local-address 5.5.5.5
set protocols bgp group internal family inet labeled-unicast resolve-vpn
set protocols bgp group internal neighbor 6.6.6.6
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0
set protocols ldp interface all
set routing-instances cust1 instance-type l2vpn
set routing-instances cust1 interface ge-0/0/0.3222
set routing-instances cust1 route-distinguisher 5.5.5.5:1
set routing-instances cust1 vrf-target target:65200:1
set routing-instances cust1 protocols l2vpn encapsulation-type ethernet-vlan
set routing-instances cust1 protocols l2vpn site cust1 site-identifier 1
set routing-instances cust1 protocols l2vpn site cust1 interface ge-0/0/0.3222

ASBR1

set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65200
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 6.6.6.6
set protocols bgp group internal family inet labeled-unicast
set protocols bgp group internal neighbor 5.5.5.5
set protocols bgp group external type external
set protocols bgp group external family inet labeled-unicast
set protocols bgp group external export PE1_LOOPBACK
set protocols bgp group external peer-as 65400
set protocols bgp group external neighbor 2.2.2.2
set protocols isis interface ge-0/0/0.0
set protocols isis interface lo0.0
set protocols ldp interface all
set policy-options policy-statement PE1_LOOPBACK from route-filter 5.5.5.5/32 exact
set policy-options policy-statement PE1_LOOPBACK then accept

CoC ASBR1

set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols mpls interface all
set protocols bgp group external type external
set protocols bgp group external family inet labeled-unicast
set protocols bgp group external peer-as 65200
set protocols bgp group external neighbor 2.2.2.1
set protocols bgp group internal type internal
set protocols bgp group internal local-address 7.7.7.7
set protocols bgp group internal family inet labeled-unicast
set protocols bgp group internal neighbor 8.8.8.8
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0
set protocols ldp interface all

CoC Core

set interfaces ge-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 8.8.8.8
set protocols bgp group internal family inet labeled-unicast
set protocols bgp group internal cluster 8.8.8.8
set protocols bgp group internal neighbor 9.9.9.9
set protocols bgp group internal neighbor 7.7.7.7
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0
set protocols ldp interface all

CoC ASBR2

set interfaces ge-0/0/0 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 5.5.5.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.9999.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set protocols mpls interface all
set protocols bgp group int type internal
set protocols bgp group int local-address 9.9.9.9
set protocols bgp group int family inet labeled-unicast
set protocols bgp group int neighbor 8.8.8.8
set protocols bgp group external type external
set protocols bgp group external family inet labeled-unicast
set protocols bgp group external peer-as 65600
set protocols bgp group external neighbor 5.5.5.2
set protocols isis interface ge-0/0/0.0
set protocols isis interface lo0.0
set protocols ldp interface all

ASBR2

set interfaces ge-0/0/0 unit 0 family inet address 5.5.5.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 6.6.6.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 10.10.10.10/32
set interfaces lo0 unit 0 family iso address 49.0000.1010.1010.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 10.10.10.10
set routing-options autonomous-system 65600
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 10.10.10.10
set protocols bgp group internal family inet labeled-unicast
set protocols bgp group internal neighbor 11.11.11.11
set protocols bgp group external type external
set protocols bgp group external family inet labeled-unicast
set protocols bgp group external export PE2_LOOPBACK
set protocols bgp group external peer-as 65400
set protocols bgp group external neighbor 5.5.5.1
set protocols isis interface ge-0/0/1.0
set protocols isis interface lo0.0
set protocols ldp interface all
set policy-options policy-statement PE2_LOOPBACK from route-filter 11.11.11.11/32 exact
set policy-options policy-statement PE2_LOOPBACK then accept

PE2

set interfaces ge-0/0/0 unit 0 family inet address 6.6.6.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 vlan-tagging
set interfaces ge-0/0/1 encapsulation flexible-ethernet-services
set interfaces ge-0/0/1 unit 3222 encapsulation vlan-ccc
set interfaces ge-0/0/1 unit 3222 vlan-id 3222
set interfaces lo0 unit 0 family inet address 11.11.11.11/32
set interfaces lo0 unit 0 family iso address 49.0000.1111.1111.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 11.11.11.11
set routing-options autonomous-system 65600
set protocols mpls interface all
set protocols bgp group internal type internal
set protocols bgp group internal local-address 11.11.11.11
set protocols bgp group internal family inet labeled-unicast resolve-vpn
set protocols bgp group internal neighbor 10.10.10.10
set protocols bgp group external type external
set protocols bgp group external multihop
set protocols bgp group external local-address 11.11.11.11
set protocols bgp group external family l2vpn signaling
set protocols bgp group external peer-as 65200
set protocols bgp group external neighbor 5.5.5.5
set protocols isis interface ge-0/0/0.0
set protocols isis interface lo0.0
set protocols ldp interface all
set routing-instances cust1 instance-type l2vpn
set routing-instances cust1 interface ge-0/0/1.3222
set routing-instances cust1 route-distinguisher 11.11.11.11:1
set routing-instances cust1 vrf-target target:65200:1
set routing-instances cust1 protocols l2vpn encapsulation-type ethernet-vlan
set routing-instances cust1 protocols l2vpn site cust1 site-identifier 2
set routing-instances cust1 protocols l2vpn site cust1 interface ge-0/0/1.3222

OSPF has been configured on both CE devices and a neighbourship has formed confirming that the layer 2 circuit is up.
