Welcome to Lab-It-Up.

Here you will find a range of virtual labs for use on both EVE-NG & GNS3.All the labs are provided free of charge and include all the commands to get the lab up and running. Also, lab templates will be provided for EVE-NG for you to import.

More labs will be added in due course so please check the site regularly for updates. In the meantime, happy labbing and good luck with your studies!

Juniper – RSVP EVPN/VPWS

4 January 20254 January 2025 nick Leave a comment

Junos Evolved is used for this lab. Commands are pretty much identical to standard Junos.

LSPs have been created between PE1 & PE3. The PE1 LSP goes through PE4 & the PE3 LSP through PE2. IS-IS is the IGP and an out of data path Route Reflector is used to reflect the relevant routes.

https://community.juniper.net/blogs/suneesh-babu/2022/11/05/evpn-vpws-validation-on-acx7000

_Exports_eve-ng_export-20250104-111343 Download

PE1

set interfaces et-0/0/0 unit 0 family inet address 1.1.1.1/30
set interfaces et-0/0/0 unit 0 family iso
set interfaces et-0/0/0 unit 0 family mpls
set interfaces et-0/0/1 unit 0 family inet address 4.4.4.2/30
set interfaces et-0/0/1 unit 0 family iso
set interfaces et-0/0/1 unit 0 family mpls
set interfaces et-0/0/2 unit 0 family inet address 1.2.2.1/30
set interfaces et-0/0/2 unit 0 family iso
set interfaces et-0/0/3 vlan-tagging
set interfaces et-0/0/3 encapsulation flexible-ethernet-services
set interfaces et-0/0/3 unit 3232 encapsulation vlan-ccc
set interfaces et-0/0/3 unit 3232 vlan-id 3232
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-instances EVPN instance-type evpn-vpws
set routing-instances EVPN protocols evpn interface et-0/0/3.3232 vpws-service-id local 32
set routing-instances EVPN protocols evpn interface et-0/0/3.3232 vpws-service-id remote 33
set routing-instances EVPN interface et-0/0/3.3232
set routing-instances EVPN route-distinguisher 5.5.5.5:3232
set routing-instances EVPN vrf-target target:65400:3232
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65400
set protocols bgp group EVPN type internal
set protocols bgp group EVPN local-address 5.5.5.5
set protocols bgp group EVPN family evpn signaling
set protocols bgp group EVPN neighbor 9.9.9.9
set protocols isis interface et-0/0/0.0 point-to-point
set protocols isis interface et-0/0/1.0 point-to-point
set protocols isis interface et-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls label-switched-path PE3 to 7.7.7.7
set protocols mpls label-switched-path PE3 primary PE3
set protocols mpls path PE3 8.8.8.8 strict
set protocols mpls interface et-0/0/0.0
set protocols mpls interface et-0/0/1.0
set protocols mpls interface lo0.0
set protocols rsvp interface et-0/0/0.0
set protocols rsvp interface et-0/0/1.0
set protocols rsvp interface lo0.0

PE2

set interfaces et-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces et-0/0/0 unit 0 family iso
set interfaces et-0/0/0 unit 0 family mpls
set interfaces et-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces et-0/0/1 unit 0 family iso
set interfaces et-0/0/1 unit 0 family mpls
set interfaces et-0/0/2 unit 0 family inet address 1.3.3.1/30
set interfaces et-0/0/2 unit 0 family iso
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65400
set protocols isis interface et-0/0/0.0 point-to-point
set protocols isis interface et-0/0/1.0 point-to-point
set protocols isis interface et-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface et-0/0/0.0
set protocols mpls interface et-0/0/1.0
set protocols mpls interface lo0.0
set protocols rsvp interface et-0/0/0.0
set protocols rsvp interface et-0/0/1.0
set protocols rsvp interface lo0.0

PE3

set interfaces et-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces et-0/0/0 unit 0 family iso
set interfaces et-0/0/0 unit 0 family mpls
set interfaces et-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces et-0/0/1 unit 0 family iso
set interfaces et-0/0/1 unit 0 family mpls
set interfaces et-0/0/2 unit 0 family inet address 1.4.4.1/30
set interfaces et-0/0/2 unit 0 family iso
set interfaces et-0/0/3 vlan-tagging
set interfaces et-0/0/3 encapsulation flexible-ethernet-services
set interfaces et-0/0/3 unit 3232 encapsulation vlan-ccc
set interfaces et-0/0/3 unit 3232 vlan-id 3232
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-instances EVPN instance-type evpn-vpws
set routing-instances EVPN protocols evpn interface et-0/0/3.3232 vpws-service-id local 33
set routing-instances EVPN protocols evpn interface et-0/0/3.3232 vpws-service-id remote 32
set routing-instances EVPN interface et-0/0/3.3232
set routing-instances EVPN route-distinguisher 7.7.7.7:3232
set routing-instances EVPN vrf-target target:65400:3232
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols bgp group EVPN type internal
set protocols bgp group EVPN local-address 7.7.7.7
set protocols bgp group EVPN family evpn signaling
set protocols bgp group EVPN neighbor 9.9.9.9
set protocols isis interface et-0/0/0.0 point-to-point
set protocols isis interface et-0/0/1.0 point-to-point
set protocols isis interface et-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls label-switched-path PE1 to 5.5.5.5
set protocols mpls label-switched-path PE1 primary PE1
set protocols mpls path PE1 6.6.6.6 strict
set protocols mpls interface et-0/0/0.0
set protocols mpls interface et-0/0/1.0
set protocols mpls interface lo0.0
set protocols rsvp interface et-0/0/0.0
set protocols rsvp interface et-0/0/1.0
set protocols rsvp interface lo0.0

PE4

set interfaces et-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces et-0/0/0 unit 0 family iso
set interfaces et-0/0/0 unit 0 family mpls
set interfaces et-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces et-0/0/1 unit 0 family iso
set interfaces et-0/0/1 unit 0 family mpls
set interfaces et-0/0/2 unit 0 family inet address 1.5.5.1/30
set interfaces et-0/0/2 unit 0 family iso
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols isis interface et-0/0/0.0 point-to-point
set protocols isis interface et-0/0/1.0 point-to-point
set protocols isis interface et-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols isis interface et-0/0/0.0 point-to-point
set protocols isis interface et-0/0/1.0 point-to-point
set protocols isis interface et-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface et-0/0/0.0
set protocols mpls interface et-0/0/1.0
set protocols mpls interface lo0.0
set protocols rsvp interface et-0/0/0.0
set protocols rsvp interface et-0/0/1.0
set protocols rsvp interface lo0.0

set interfaces et-0/0/1 unit 0 family inet address 1.2.2.2/30
set interfaces et-0/0/1 unit 0 family iso
set interfaces et-0/0/2 unit 0 family inet address 1.3.3.2/30
set interfaces et-0/0/2 unit 0 family iso
set interfaces et-0/0/3 unit 0 family inet address 1.4.4.2/30
set interfaces et-0/0/3 unit 0 family iso
set interfaces et-0/0/4 unit 0 family inet address 1.5.5.2/30
set interfaces et-0/0/4 unit 0 family iso
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.0000.0000.00
set routing-options resolution rib bgp.evpn.0 resolution-ribs inet.0
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set protocols bgp group EVPN type internal
set protocols bgp group EVPN local-address 9.9.9.9
set protocols bgp group EVPN family evpn signaling
set protocols bgp group EVPN cluster 9.9.9.9
set protocols bgp group EVPN neighbor 5.5.5.5
set protocols bgp group EVPN neighbor 7.7.7.7
set protocols isis interface et-0/0/1.0 point-to-point
set protocols isis interface et-0/0/2.0 point-to-point
set protocols isis interface et-0/0/3.0 point-to-point
set protocols isis interface et-0/0/4.0 point-to-point
set protocols isis interface lo0.0 passive

The VPWS instance will now be up.

OSPF configured on the 2 CE devices confirming the layer 2 circuit.

Juniper – Segment Routing Traffic Engineering

29 December 202429 December 2024 nick Leave a comment

Again we will use vjunos router for this lab. Aim of the lab is to direct traffic for the VPWS circuit over a certain path. Traffic from PE1 will go via PE4 and traffic from PE3 will go via PE2.

IS-IS is used as the IGP (could use OSPF if preferred) and an out of path route reflector reflects routes to the PE devices.

https://www.juniper.net/documentation/us/en/software/junos/mpls/topics/topic-map/segment-routing-lsp-configuration.html

_Exports_eve-ng_export-20241229-175412 Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces ge-0/0/2 unit 0 family inet address 1.2.2.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 vlan-tagging
set interfaces ge-0/0/3 encapsulation flexible-ethernet-services
set interfaces ge-0/0/3 unit 545 encapsulation vlan-ccc
set interfaces ge-0/0/3 unit 545 vlan-id 545
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-instances VPWS instance-type evpn-vpws
set routing-instances VPWS protocols evpn interface ge-0/0/3.545 vpws-service-id local 545
set routing-instances VPWS protocols evpn interface ge-0/0/3.545 vpws-service-id remote 546
set routing-instances VPWS interface ge-0/0/3.545
set routing-instances VPWS route-distinguisher 5.5.5.5:545
set routing-instances VPWS vrf-target target:65400:545
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65400
set protocols bgp group VPWS type internal
set protocols bgp group VPWS local-address 5.5.5.5
set protocols bgp group VPWS family evpn signaling
set protocols bgp group VPWS neighbor 9.9.9.9
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0 passive
set protocols isis source-packet-routing srgb start-label 80000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 50
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis traffic-engineering l3-unicast-topology
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols source-packet-routing segment-list PE3 hop1 label 80080
set protocols source-packet-routing source-routing-path PE3 to 7.7.7.7
set protocols source-packet-routing source-routing-path PE3 color 100
set protocols source-packet-routing source-routing-path PE3 primary PE3

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces ge-0/0/2 unit 0 family inet address 1.3.3.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 vlan-tagging
set interfaces ge-0/0/3 encapsulation flexible-ethernet-services
set interfaces ge-0/0/3 unit 2121 encapsulation vlan-ccc
set interfaces ge-0/0/3 unit 2121 vlan-id 2121
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65400
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0 passive
set protocols isis source-packet-routing srgb start-label 80000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 60
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0

PE3

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces ge-0/0/2 unit 0 family inet address 1.4.4.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 vlan-tagging
set interfaces ge-0/0/3 encapsulation flexible-ethernet-services
set interfaces ge-0/0/3 unit 545 encapsulation vlan-ccc
set interfaces ge-0/0/3 unit 545 vlan-id 545
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-instances VPWS instance-type evpn-vpws
set routing-instances VPWS protocols evpn interface ge-0/0/3.545 vpws-service-id local 546
set routing-instances VPWS protocols evpn interface ge-0/0/3.545 vpws-service-id remote 545
set routing-instances VPWS interface ge-0/0/3.545
set routing-instances VPWS route-distinguisher 7.7.7.7:545
set routing-instances VPWS vrf-target target:65400:545
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols bgp group VPWS type internal
set protocols bgp group VPWS local-address 7.7.7.7
set protocols bgp group VPWS family evpn signaling
set protocols bgp group VPWS neighbor 9.9.9.9
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0 passive
set protocols isis source-packet-routing srgb start-label 80000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 70
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols source-packet-routing segment-list PE1 hop1 label 80060
set protocols source-packet-routing source-routing-path PE1 to 5.5.5.5
set protocols source-packet-routing source-routing-path PE1 color 100
set protocols source-packet-routing source-routing-path PE1 primary PE1

PE4

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces ge-0/0/2 unit 0 family inet address 1.5.5.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 vlan-tagging
set interfaces ge-0/0/3 encapsulation flexible-ethernet-services
set interfaces ge-0/0/3 unit 2121 encapsulation vlan-ccc
set interfaces ge-0/0/3 unit 2121 vlan-id 2121
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0 passive
set protocols isis source-packet-routing srgb start-label 80000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 80
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0

set interfaces ge-0/0/1 unit 0 family inet address 1.2.2.2/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family inet address 1.3.3.2/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 unit 0 family inet address 1.4.4.2/30
set interfaces ge-0/0/3 unit 0 family iso
set interfaces ge-0/0/4 unit 0 family inet address 1.5.5.2/30
set interfaces ge-0/0/4 unit 0 family iso
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.0000.0000.00
set routing-options rib inet.3
set routing-options resolution rib bgp.evpn.0 resolution-ribs inet.0
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set protocols bgp group VPWS type internal
set protocols bgp group VPWS local-address 9.9.9.9
set protocols bgp group VPWS family evpn signaling
set protocols bgp group VPWS cluster 9.9.9.9
set protocols bgp group VPWS neighbor 5.5.5.5
set protocols bgp group VPWS neighbor 7.7.7.7
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface ge-0/0/3.0
set protocols isis interface ge-0/0/4.0
set protocols isis interface lo0.0 passive

If you check the routing table of either PE1 or PE3 you will find a new table called inetcolor.0 as a color has been applied to the traffic engineering.

OSPF has been configured on both CE devices confirming the VPWS circuit is up.

Juniper – Segment Routing EVPN E-Tree

22 December 202422 December 2024 nick Leave a comment

Rather than the vMX, vJunos router is used for this lab & a Route Reflector is thrown into the mix to make things a little more interesting. IS-IS used as the IGP. CE1 is root & CE2 & CE3 are configured as leaves so they are not able to forward traffic to each other.

https://www.juniper.net/documentation/us/en/software/junos/evpn/topics/example/example-etree-service-evpn-configuring.html

_Exports_eve-ng_export-20241222-131321 Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces ge-0/0/2 unit 0 family inet address 1.2.2.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 flexible-vlan-tagging
set interfaces ge-0/0/3 encapsulation flexible-ethernet-services
set interfaces ge-0/0/3 unit 545 encapsulation vlan-bridge
set interfaces ge-0/0/3 unit 545 vlan-id 545
set interfaces ge-0/0/3 unit 545 etree-ac-role root
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-instances ETREE instance-type evpn
set routing-instances ETREE protocols evpn interface ge-0/0/3.545
set routing-instances ETREE protocols evpn evpn-etree
set routing-instances ETREE vlan-id 545
set routing-instances ETREE interface ge-0/0/3.545
set routing-instances ETREE route-distinguisher 5.5.5.5:545
set routing-instances ETREE vrf-target target:65400:545
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65400
set protocols bgp group ETREE type internal
set protocols bgp group ETREE local-address 5.5.5.5
set protocols bgp group ETREE family evpn signaling
set protocols bgp group ETREE neighbor 9.9.9.9
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0 passive
set protocols isis source-packet-routing srgb start-label 80000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 50
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces ge-0/0/2 unit 0 family inet address 1.3.3.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65400
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0 passive
set protocols isis source-packet-routing srgb start-label 80000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 60
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0

PE3

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces ge-0/0/2 unit 0 family inet address 1.4.4.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 flexible-vlan-tagging
set interfaces ge-0/0/3 encapsulation flexible-ethernet-services
set interfaces ge-0/0/3 unit 545 encapsulation vlan-bridge
set interfaces ge-0/0/3 unit 545 vlan-id 545
set interfaces ge-0/0/3 unit 545 etree-ac-role leaf
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-instances ETREE instance-type evpn
set routing-instances ETREE protocols evpn interface ge-0/0/3.545
set routing-instances ETREE protocols evpn evpn-etree
set routing-instances ETREE vlan-id 545
set routing-instances ETREE interface ge-0/0/3.545
set routing-instances ETREE route-distinguisher 7.7.7.7:545
set routing-instances ETREE vrf-target target:65400:545
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols bgp group ETREE type internal
set protocols bgp group ETREE local-address 7.7.7.7
set protocols bgp group ETREE family evpn signaling
set protocols bgp group ETREE neighbor 9.9.9.9
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0 passive
set protocols isis source-packet-routing srgb start-label 80000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 70
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0

PE4

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces ge-0/0/2 unit 0 family inet address 1.5.5.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 flexible-vlan-tagging
set interfaces ge-0/0/3 encapsulation flexible-ethernet-services
set interfaces ge-0/0/3 unit 545 encapsulation vlan-bridge
set interfaces ge-0/0/3 unit 545 vlan-id 545
set interfaces ge-0/0/3 unit 545 etree-ac-role leaf
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.0000.0000.00
set interfaces lo0 unit 0 family mpls
set routing-instances ETREE instance-type evpn
set routing-instances ETREE protocols evpn interface ge-0/0/3.545
set routing-instances ETREE protocols evpn evpn-etree
set routing-instances ETREE vlan-id 545
set routing-instances ETREE interface ge-0/0/3.545
set routing-instances ETREE route-distinguisher 8.8.8.8:545
set routing-instances ETREE vrf-target target:65400:545
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols bgp group ETREE type internal
set protocols bgp group ETREE local-address 8.8.8.8
set protocols bgp group ETREE family evpn signaling
set protocols bgp group ETREE neighbor 9.9.9.9
set protocols isis interface ge-0/0/0.0
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface lo0.0 passive
set protocols isis source-packet-routing srgb start-label 80000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 80
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0

set interfaces ge-0/0/1 unit 0 family inet address 1.2.2.2/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family inet address 1.3.3.2/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/3 unit 0 family inet address 1.4.4.2/30
set interfaces ge-0/0/3 unit 0 family iso
set interfaces ge-0/0/4 unit 0 family inet address 1.5.5.2/30
set interfaces ge-0/0/4 unit 0 family iso
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.0000.0000.00
set routing-options resolution rib bgp.evpn.0 resolution-ribs inet.0
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set protocols bgp group ETREE type internal
set protocols bgp group ETREE local-address 9.9.9.9
set protocols bgp group ETREE family evpn signaling
set protocols bgp group ETREE cluster 9.9.9.9
set protocols bgp group ETREE neighbor 5.5.5.5
set protocols bgp group ETREE neighbor 7.7.7.7
set protocols bgp group ETREE neighbor 8.8.8.8
set protocols isis interface ge-0/0/1.0
set protocols isis interface ge-0/0/2.0
set protocols isis interface ge-0/0/3.0
set protocols isis interface ge-0/0/4.0
set protocols isis interface lo0.0 passive

The attachment circuits will now be up

OSPF has been configured on the CE devices. As root, CE1 will be neighbours with both CE2 & CE3

Leaves will only be neighbours with root. Output from CE2 confirms this.

Cisco IOS XE – RSVP L3VPN

3 December 20243 December 2024 nick Leave a comment

We have done a L2VPN on IOS XE so lets give a L3VPN a try. RSVP is used for signalling, IS-IS for the IGP and P1 acting as a route reflector. 2 Cisco CE devices with OSPF configured to the PEs. Will throw in an OSPF sham link for a bit of fun.

https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/mp_l3_vpns/configuration/xe-17/mp-l3-vpns-xe-17-book.html

_Exports_eve-ng_export-20241203-203029 Download

PE1

hostname pe1

ip vrf CE1
rd 5.5.5.5:100
route-target export 65200:100
route-target import 65200:100

mpls traffic-eng tunnels

interface Loopback0
ip address 5.5.5.5 255.255.255.255
ip router isis 1
isis circuit-type level-2-only

interface Loopback1
ip vrf forwarding CE1
ip address 22.22.22.22 255.255.255.255

interface Tunnel1
ip unnumbered Loopback0
tunnel mode mpls traffic-eng
tunnel destination 7.7.7.7
tunnel mpls traffic-eng autoroute announce
tunnel mpls traffic-eng path-option 1 dynamic

interface GigabitEthernet1
ip address 1.1.1.1 255.255.255.252
ip router isis 1
mpls ip
mpls traffic-eng tunnels
isis circuit-type level-2-only
isis network point-to-point
ip rsvp bandwidth percent 50
ip rsvp signalling hello

interface GigabitEthernet2
ip vrf forwarding CE1
ip address 10.1.1.1 255.255.255.0
ip ospf 1 area 0

router ospf 1 vrf CE1
area 0 sham-link 22.22.22.22 33.33.33.33
redistribute bgp 65200

router isis 1
net 49.0000.5555.5555.5555.00
is-type level-2-only
metric-style wide
mpls traffic-eng router-id Loopback0
mpls traffic-eng level-2

router bgp 65200
bgp log-neighbor-changes
neighbor 6.6.6.6 remote-as 65200
neighbor 6.6.6.6 update-source Loopback0

address-family vpnv4
neighbor 6.6.6.6 activate
neighbor 6.6.6.6 send-community extended
exit-address-family

address-family ipv4 vrf CE1
network 22.22.22.22 mask 255.255.255.255
redistribute ospf 1
exit-address-family

hostname p1

mpls traffic-eng tunnels

interface Loopback0
ip address 6.6.6.6 255.255.255.255
ip router isis 1
isis circuit-type level-2-only

interface GigabitEthernet1
ip address 1.1.1.2 255.255.255.252
ip router isis 1
mpls ip
mpls traffic-eng tunnels
isis circuit-type level-2-only
isis network point-to-point
ip rsvp bandwidth percent 50
ip rsvp signalling hello

interface GigabitEthernet2
ip address 2.2.2.1 255.255.255.252
ip router isis 1
mpls ip
mpls traffic-eng tunnels
isis circuit-type level-2-only
isis network point-to-point
ip rsvp bandwidth percent 50
ip rsvp signalling hello

router isis 1
net 49.0000.6666.6666.6666.00
is-type level-2-only
metric-style wide
mpls traffic-eng router-id Loopback0
mpls traffic-eng level-2

router bgp 65200
bgp log-neighbor-changes
neighbor 5.5.5.5 remote-as 65200
neighbor 5.5.5.5 update-source Loopback0
neighbor 7.7.7.7 remote-as 65200
neighbor 7.7.7.7 update-source Loopback0

address-family vpnv4
neighbor 5.5.5.5 activate
neighbor 5.5.5.5 send-community extended
neighbor 5.5.5.5 route-reflector-client
neighbor 7.7.7.7 activate
neighbor 7.7.7.7 send-community extended
neighbor 7.7.7.7 route-reflector-client
exit-address-family

PE2

hostname pe2

ip vrf CE2
rd 7.7.7.7:100
route-target export 65200:100
route-target import 65200:100

mpls traffic-eng tunnels

interface Loopback0
ip address 7.7.7.7 255.255.255.255
ip router isis 1
isis circuit-type level-2-only

interface Loopback1
ip vrf forwarding CE2
ip address 33.33.33.33 255.255.255.255

interface Tunnel1
ip unnumbered Loopback0
tunnel mode mpls traffic-eng
tunnel destination 5.5.5.5
tunnel mpls traffic-eng autoroute announce
tunnel mpls traffic-eng path-option 1 dynamic

interface GigabitEthernet1
ip address 2.2.2.2 255.255.255.252
ip router isis 1
mpls ip
mpls traffic-eng tunnels
isis circuit-type level-2-only
isis network point-to-point
ip rsvp bandwidth percent 50
ip rsvp signalling hello

interface GigabitEthernet2
ip vrf forwarding CE2
ip address 10.2.2.1 255.255.255.0
ip ospf 1 area 0

router ospf 1 vrf CE2
router-id 10.2.2.1
area 0 sham-link 33.33.33.33 22.22.22.22
redistribute bgp 65200

router isis 1
net 49.0000.7777.7777.7777.00
is-type level-2-only
metric-style wide
mpls traffic-eng router-id Loopback0
mpls traffic-eng level-2

router bgp 65200
bgp log-neighbor-changes
neighbor 6.6.6.6 remote-as 65200
neighbor 6.6.6.6 update-source Loopback0

address-family vpnv4
neighbor 6.6.6.6 activate
neighbor 6.6.6.6 send-community extended
exit-address-family

address-family ipv4 vrf CE2
network 33.33.33.33 mask 255.255.255.255
redistribute ospf 1
exit-address-family

The L3VPN will now be up and you can confirm by checking the routing tables of the CE devices. In this instance the sham links were configured with IP addresses of 22.22.22.22/32 & 33.33.33.33/32.

Cisco IOS XE – Segment Routing VPLS

27 November 202427 November 2024 nick Leave a comment

Instead of using LDP or RSVP, IS-IS Segment Routing is used. P1 acts as a route reflector. A simple lab with, as usual, 2 Cisco CE devices. EIGRP is used between them instead of OSPF.

https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/seg_routing/configuration/xe-17/segrt-xe-17-book/m_sr-ospf.html

_Exports_eve-ng_export-20241127-194614 Download

PE1

hostname pe1

l2 vfi VPLS autodiscovery
vpn id 444
bridge-domain 1
rd 5.5.5.5:444
route-target export 65200:444
route-target import 65200:444

interface Loopback0
ip address 5.5.5.5 255.255.255.255
ip router isis 1

interface GigabitEthernet1
ip address 1.1.1.1 255.255.255.252
ip router isis 1
negotiation auto
no mpls ldp igp autoconfig
no mop enabled
no mop sysid
isis circuit-type level-2-only
isis network point-to-point

interface GigabitEthernet2
no ip address
negotiation auto
no mop enabled
no mop sysid
service instance 1 ethernet
encapsulation dot1q 444
bridge-domain 1

segment-routing mpls
set-attributes
address-family ipv4
sr-label-preferred
exit-address-family

global-block 40000 45000

connected-prefix-sid-map
address-family ipv4
5.5.5.5/32 index 100 range 1
exit-address-family


router isis 1
net 49.0000.5555.5555.5555.00
is-type level-2-only
metric-style wide
segment-routing mpls

router bgp 65200
bgp log-neighbor-changes
neighbor 6.6.6.6 remote-as 65200
neighbor 6.6.6.6 update-source Loopback0

address-family ipv4
neighbor 6.6.6.6 activate
exit-address-family

address-family l2vpn vpls
neighbor 6.6.6.6 activate
neighbor 6.6.6.6 send-community extended
neighbor 6.6.6.6 next-hop-self

hostname p1

interface Loopback0
ip address 6.6.6.6 255.255.255.255
ip router isis 1

interface GigabitEthernet1
ip address 1.1.1.2 255.255.255.252
ip router isis 1
negotiation auto
no mpls ldp igp autoconfig
no mop enabled
no mop sysid
isis circuit-type level-2-only
isis network point-to-point

interface GigabitEthernet2
ip address 2.2.2.1 255.255.255.252
ip router isis 1
negotiation auto
no mpls ldp igp autoconfig
no mop enabled
no mop sysid
isis circuit-type level-2-only
isis network point-to-point

segment-routing mpls
set-attributes
address-family ipv4
sr-label-preferred
exit-address-family

global-block 40000 45000

connected-prefix-sid-map
address-family ipv4
6.6.6.6/32 index 200 range 1
exit-address-family


router isis 1
net 49.0000.6666.6666.6666.00
is-type level-2-only
metric-style wide
segment-routing mpls

router bgp 65200
bgp log-neighbor-changes
neighbor 5.5.5.5 remote-as 65200
neighbor 5.5.5.5 update-source Loopback0
neighbor 7.7.7.7 remote-as 65200
neighbor 7.7.7.7 update-source Loopback0

address-family ipv4
neighbor 5.5.5.5 activate
neighbor 7.7.7.7 activate
exit-address-family

address-family l2vpn vpls
neighbor 5.5.5.5 activate
neighbor 5.5.5.5 send-community extended
neighbor 5.5.5.5 route-reflector-client
neighbor 7.7.7.7 activate
neighbor 7.7.7.7 send-community extended
neighbor 7.7.7.7 route-reflector-client

PE2

hostname pe2

l2 vfi VPLS autodiscovery
vpn id 444
bridge-domain 1
rd 7.7.7.7:444
route-target export 65200:444
route-target import 65200:444

interface Loopback0
ip address 7.7.7.7 255.255.255.255
ip router isis 1

interface GigabitEthernet1
ip address 2.2.2.2 255.255.255.252
ip router isis 1
negotiation auto
no mpls ldp igp autoconfig
no mop enabled
no mop sysid
isis circuit-type level-2-only
isis network point-to-point

interface GigabitEthernet2
no ip address
negotiation auto
no mop enabled
no mop sysid
service instance 1 ethernet
encapsulation dot1q 444
bridge-domain 1

segment-routing mpls
set-attributes
address-family ipv4
sr-label-preferred
exit-address-family

global-block 40000 45000

connected-prefix-sid-map
address-family ipv4
7.7.7.7/32 index 300 range 1
exit-address-family

router isis 1
net 49.0000.7777.7777.7777.00
is-type level-2-only
metric-style wide
segment-routing mpls

router bgp 65200
bgp log-neighbor-changes
neighbor 6.6.6.6 remote-as 65200
neighbor 6.6.6.6 update-source Loopback0

address-family ipv4
neighbor 6.6.6.6 activate
exit-address-family

address-family l2vpn vpls
neighbor 6.6.6.6 activate
neighbor 6.6.6.6 send-community extended
neighbor 6.6.6.6 next-hop-self

EIGRP is now up between the 2 CE devices confirming VPLS is up and running

Arista – EVPN VPWS

27 November 202427 November 2024 nick Leave a comment

LDP is used for signalling and IS-IS for the IGP with P1 acting as a route reflector. 2 Cisco CE devices with OSPF configured on each.

https://www.arista.com/en/um-eos/eos-configuring-evpn#xx1117976

_Exports_eve-ng_export-20241127-105106 Download

PE1

service routing protocols model multi-agent

hostname pe1

interface Ethernet1
no switchport
ip address 1.1.1.1/30
isis enable 1

interface Ethernet2
no switchport
interface Ethernet2.909
encapsulation dot1q vlan 909

interface Loopback0
ip address 5.5.5.5/32
isis enable 1

ip routing

mpls ip

mpls ldp
no shutdown

patch panel
patch VPWS
connector 1 interface Ethernet2.909
connector 2 pseudowire bgp vpws PE2 pseudowire VPWS

router bgp 65400
router-id 5.5.5.5
neighbor 6.6.6.6 remote-as 65400
neighbor 6.6.6.6 update-source Loopback0
neighbor 6.6.6.6 send-community

vpws PE2
rd 5.5.5.5:909
route-target import export evpn 65400:909
mpls control-word

pseudowire VPWS
evpn vpws id local 909 remote 910

address-family evpn
neighbor default encapsulation mpls next-hop-self source-interface Loopback0
neighbor 6.6.6.6 activate

router isis 1
net 49.0000.5555.5555.5555.00
is-type level-2
address-family ipv4 unicast

service routing protocols model multi-agent

hostname p1

interface Ethernet1
no switchport
ip address 1.1.1.2/30
isis enable 1

interface Ethernet2
no switchport
ip address 2.2.2.1/30
isis enable 1

interface Loopback0
ip address 6.6.6.6/32
isis enable 1

ip routing

mpls ip

mpls ldp
no shutdown

router bgp 65400
router-id 6.6.6.6
neighbor 5.5.5.5 remote-as 65400
neighbor 5.5.5.5 update-source Loopback0
neighbor 5.5.5.5 route-reflector-client
neighbor 5.5.5.5 send-community
neighbor 7.7.7.7 remote-as 65400
neighbor 7.7.7.7 update-source Loopback0
neighbor 7.7.7.7 route-reflector-client
neighbor 7.7.7.7 send-community

address-family evpn
neighbor default encapsulation mpls next-hop-self source-interface Loopback0
neighbor 5.5.5.5 activate
neighbor 7.7.7.7 activate

router isis 1
net 49.0000.6666.6666.6666.00
is-type level-2
address-family ipv4 unicast

PE2

service routing protocols model multi-agent

hostname pe2

interface Ethernet1
no switchport
ip address 2.2.2.2/30
isis enable 1

interface Ethernet2
no switchport
interface Ethernet2.909
encapsulation dot1q vlan 909

interface Loopback0
ip address 7.7.7.7/32
isis enable 1

ip routing

mpls ip

mpls ldp
no shutdown

patch panel
patch VPWS
connector 1 interface Ethernet2.909
connector 2 pseudowire bgp vpws PE2 pseudowire VPWS

router bgp 65400
neighbor 6.6.6.6 remote-as 65400
neighbor 6.6.6.6 update-source Loopback0
neighbor 6.6.6.6 send-community

vpws PE2
rd 7.7.7.7:909
route-target import export evpn 65400:909
mpls control-word

pseudowire VPWS
evpn vpws id local 910 remote 909

address-family evpn
neighbor default encapsulation mpls next-hop-self source-interface Loopback0
neighbor 6.6.6.6 activate

router isis 1
net 49.0000.7777.7777.7777.00
is-type level-2
address-family ipv4 unicast

OSPF is now up on the 2 Cisco CE devices, confirming layer 2 connectivity.

Juniper vMX – Inter-AS BGP L2VPN Option B

10 November 202410 November 2024 nick Leave a comment

Slight difference to Option A topology. Still running Segment Routing in AS65200 but AS65400 is now running RSVP. Great article linked below from Chris Parker who explains Option B in more detail (click on Network Fun Times link). OSPF configured on the 2 Cisco CE devices.

Network Fun Times Inter-AS Option B

_Exports_eve-ng_export-20241110-130119 Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 vlan-tagging
set interfaces ge-0/0/0 encapsulation flexible-ethernet-services
set interfaces ge-0/0/0 unit 123 encapsulation vlan-ccc
set interfaces ge-0/0/0 unit 123 vlan-id 123
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/2.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 5.5.5.5
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 20
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L2VPN instance-type l2vpn
set routing-instances L2VPN interface ge-0/0/0.123
set routing-instances L2VPN route-distinguisher 5.5.5.5:123
set routing-instances L2VPN vrf-target target:65200:123
set routing-instances L2VPN protocols l2vpn encapsulation-type ethernet-vlan
set routing-instances L2VPN protocols l2vpn site L2VPN site-identifier 1
set routing-instances L2VPN protocols l2vpn site L2VPN interface ge-0/0/0.123

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 6.6.6.6
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL cluster 6.6.6.6
set protocols bgp group INTERNAL neighbor 5.5.5.5
set protocols bgp group INTERNAL neighbor 33.33.33.33
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 25
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

ASBR1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 10.33.33.1/30
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 33.33.33.33/32
set interfaces lo0 unit 0 family iso address 49.0000.3333.3333.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 33.33.33.33
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols mpls interface ge-0/0/1.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 33.33.33.33
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols bgp group AS65400 type external
set protocols bgp group AS65400 family l2vpn signaling
set protocols bgp group AS65400 peer-as 65400
set protocols bgp group AS65400 neighbor 10.33.33.2
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 30
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

ASBR2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 10.33.33.2/30
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.7777.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set routing-options resolution
set protocols rsvp interface ge-0/0/1.0
set protocols rsvp interface lo0.0
set protocols mpls label-switched-path PE2 to 8.8.8.8
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols mpls interface ge-0/0/0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 7.7.7.7
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols bgp group AS65200 type external
set protocols bgp group AS65200 family l2vpn signaling
set protocols bgp group AS65200 peer-as 65200
set protocols bgp group AS65200 neighbor 10.33.33.1
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 5.5.5.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces fxp0 unit 0 family inet dhcp vendor-id Juniper-vmx-VM67309BAAF3
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.9999.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set routing-options resolution rib bgp.l2vpn.0 resolution-ribs inet.0
set protocols rsvp interface ge-0/0/0.0
set protocols rsvp interface ge-0/0/1.0
set protocols rsvp interface lo0.0
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 9.9.9.9
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL cluster 9.9.9.9
set protocols bgp group INTERNAL neighbor 7.7.7.7
set protocols bgp group INTERNAL neighbor 8.8.8.8
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 5.5.5.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 vlan-tagging
set interfaces ge-0/0/1 encapsulation flexible-ethernet-services
set interfaces ge-0/0/1 unit 123 encapsulation vlan-ccc
set interfaces ge-0/0/1 unit 123 vlan-id 123
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.8888.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols rsvp interface ge-0/0/0.0
set protocols rsvp interface lo0.0
set protocols mpls label-switched-path ASBR2 to 7.7.7.7
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 8.8.8.8
set protocols bgp group INTERNAL family l2vpn signaling
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L2VPN instance-type l2vpn
set routing-instances L2VPN interface ge-0/0/1.123
set routing-instances L2VPN route-distinguisher 8.8.8.8:123
set routing-instances L2VPN vrf-target target:65200:123
set routing-instances L2VPN protocols l2vpn encapsulation-type ethernet-vlan
set routing-instances L2VPN protocols l2vpn site L2VPN site-identifier 2
set routing-instances L2VPN protocols l2vpn site L2VPN interface ge-0/0/1.123

OSPF is now up on the 2 Cisco CE devices, confirming the layer 2 VPN is established.

Juniper vMX – Inter-AS L3VPN Option A

10 November 202410 November 2024 nick Leave a comment

This topology uses option A and, as usual, 2 Cisco devices as CEs. BGP is used for routing between PEs & CEs. AS65200 is running Segment Routing and AS65400 LDP.

https://www.juniper.net/documentation/us/en/software/junos/vpn-l3/topics/topic-map/l3-vpns-interprovider.html#:~:text=Interprovider%20Layer%203%20VPN%20Option%20A%20provides%20interprovider%20VRF%2Dto,is%20the%20least%20scalable%20solution.

_Exports_eve-ng_export-20241109-220516 Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 10.1.1.1/24
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/2.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 5.5.5.5
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 20
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L3VPN instance-type vrf
set routing-instances L3VPN interface ge-0/0/0.0
set routing-instances L3VPN route-distinguisher 5.5.5.5:1
set routing-instances L3VPN vrf-target target:65200:1
set routing-instances L3VPN vrf-table-label
set routing-instances L3VPN protocols bgp group L3VPN type external
set routing-instances L3VPN protocols bgp group L3VPN as-override
set routing-instances L3VPN protocols bgp group L3VPN neighbor 10.1.1.254 peer-as 65444

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 6.6.6.6
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL cluster 6.6.6.6
set protocols bgp group INTERNAL neighbor 5.5.5.5
set protocols bgp group INTERNAL neighbor 33.33.33.33
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 25
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

ASBR1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 10.33.33.1/30
set interfaces lo0 unit 0 family inet address 33.33.33.33/32
set interfaces lo0 unit 0 family iso address 49.0000.3333.3333.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 33.33.33.33
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 33.33.33.33
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols isis source-packet-routing srgb start-label 33000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 30
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L3VPN instance-type vrf
set routing-instances L3VPN interface ge-0/0/1.0
set routing-instances L3VPN route-distinguisher 33.33.33.33:1
set routing-instances L3VPN vrf-target target:65200:1
set routing-instances L3VPN protocols bgp group AS65400 type external
set routing-instances L3VPN protocols bgp group AS65400 neighbor 10.33.33.2 peer-as 65400

ASBR2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 10.33.33.2/30
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.7777.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 7.7.7.7
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/1.0
set protocols ldp interface lo0.0
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L3VPN instance-type vrf
set routing-instances L3VPN interface ge-0/0/0.0
set routing-instances L3VPN route-distinguisher 7.7.7.7:1
set routing-instances L3VPN vrf-target target:65200:1
set routing-instances L3VPN protocols bgp group AS65200 type external
set routing-instances L3VPN protocols bgp group AS65200 neighbor 10.33.33.1 peer-as 65200

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 5.5.5.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.9999.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 9.9.9.9
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL cluster 9.9.9.9
set protocols bgp group INTERNAL neighbor 7.7.7.7
set protocols bgp group INTERNAL neighbor 8.8.8.8
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/0.0
set protocols ldp interface ge-0/0/1.0
set protocols ldp interface lo0.0
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 5.5.5.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 11.1.1.1/24
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.8888.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 8.8.8.8
set protocols bgp group INTERNAL family inet-vpn unicast
set protocols bgp group INTERNAL export NHS
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/0.0
set protocols ldp interface lo0.0
set policy-options policy-statement NHS term 1 from protocol bgp
set policy-options policy-statement NHS term 1 then next-hop self
set routing-instances L3VPN instance-type vrf
set routing-instances L3VPN interface ge-0/0/1.0
set routing-instances L3VPN route-distinguisher 8.8.8.8:1
set routing-instances L3VPN vrf-target target:65200:1
set routing-instances L3VPN vrf-table-label
set routing-instances L3VPN protocols bgp group L3VPN type external
set routing-instances L3VPN protocols bgp group L3VPN as-override
set routing-instances L3VPN protocols bgp group L3VPN neighbor 11.1.1.254 peer-as 65444

The 2 CE devices will now have IP connectivity and you can see the respective routes have been learnt on both sides.

Juniper vMX – Carrier of Carriers EVPN VPLS

9 November 202410 November 2024 nick Leave a comment

This lab is slightly different to the other Carrier of Carrier lab where LDP was used in each AS. In this lab, AS65200 is using LDP, AS65400 RSVP & AS65600 Segment Routing. 2 Cisco vIOS devices used as CE devices

https://www.juniper.net/documentation/us/en/software/junos/vpn-l3/topics/topic-map/l3-vpns-carrier-carrier.html

_Exports_eve-ng_export-20241109-101638 Download

PE1

set interfaces ge-0/0/0 vlan-tagging
set interfaces ge-0/0/0 encapsulation vlan-vpls
set interfaces ge-0/0/0 unit 909 encapsulation vlan-vpls
set interfaces ge-0/0/0 unit 909 vlan-id 909
set interfaces ge-0/0/0 unit 909 family vpls
set interfaces ge-0/0/2 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/2 unit 0 family iso
set interfaces ge-0/0/2 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.5555.5555.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/2.0
set protocols mpls interface lo0.0
set protocols bgp group AS65600 type external
set protocols bgp group AS65600 multihop
set protocols bgp group AS65600 local-address 5.5.5.5
set protocols bgp group AS65600 family evpn signaling
set protocols bgp group AS65600 peer-as 65600
set protocols bgp group AS65600 neighbor 11.11.11.11
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 5.5.5.5
set protocols bgp group INTERNAL family inet labeled-unicast resolve-vpn
set protocols bgp group INTERNAL neighbor 6.6.6.6
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/2.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/2.0
set protocols ldp interface lo0.0
set routing-instances vpls instance-type evpn
set routing-instances vpls interface ge-0/0/0.909
set routing-instances vpls route-distinguisher 5.5.5.5:909
set routing-instances vpls vrf-target target:65200:909
set routing-instances vpls protocols vpls site-range 1000
set routing-instances vpls protocols vpls no-tunnel-services
set routing-instances vpls protocols vpls site vpls-1 site-identifier 1
set routing-instances vpls protocols vpls site vpls-1 interface ge-0/0/0.909
set routing-instances vpls protocols evpn interface ge-0/0/0.909

ASBR1

set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.2.2.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.6666.6666.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65200
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 6.6.6.6
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL neighbor 5.5.5.5
set protocols bgp group AS65400 type external
set protocols bgp group AS65400 family inet labeled-unicast
set protocols bgp group AS65400 export PE1_LOOPBACK
set protocols bgp group AS65400 peer-as 65400
set protocols bgp group AS65400 neighbor 2.2.2.2
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols ldp interface ge-0/0/0.0
set protocols ldp interface lo0.0
set policy-options policy-statement PE1_LOOPBACK from route-filter 5.5.5.5/32 exact
set policy-options policy-statement PE1_LOOPBACK then accept

CoC ASBR1

set interfaces ge-0/0/0 unit 0 family inet address 2.2.2.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 3.3.3.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.7777.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols rsvp interface ge-0/0/1.0
set protocols rsvp interface lo0.0
set protocols mpls label-switched-path ASBR2 to 9.9.9.9
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group AS65200 type external
set protocols bgp group AS65200 family inet labeled-unicast
set protocols bgp group AS65200 peer-as 65200
set protocols bgp group AS65200 neighbor 2.2.2.1
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 7.7.7.7
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL neighbor 8.8.8.8
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive

CoC Core

set interfaces ge-0/0/0 unit 0 family inet address 3.3.3.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 4.4.4.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 8.8.8.8/32
set interfaces lo0 unit 0 family iso address 49.0000.8888.8888.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 8.8.8.8
set routing-options autonomous-system 65400
set protocols rsvp interface ge-0/0/0.0
set protocols rsvp interface ge-0/0/1.0
set protocols rsvp interface lo0.0
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 8.8.8.8
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL cluster 8.8.8.8
set protocols bgp group INTERNAL neighbor 9.9.9.9
set protocols bgp group INTERNAL neighbor 7.7.7.7
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive

CoC ASBR2

set interfaces ge-0/0/0 unit 0 family inet address 4.4.4.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 5.5.5.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 9.9.9.9/32
set interfaces lo0 unit 0 family iso address 49.0000.9999.9999.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 9.9.9.9
set routing-options autonomous-system 65400
set protocols rsvp interface ge-0/0/0.0
set protocols rsvp interface lo0.0
set protocols mpls label-switched-path ASBR1 to 7.7.7.7
set protocols mpls interface ge-0/0/0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 9.9.9.9
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL neighbor 8.8.8.8
set protocols bgp group AS65600 type external
set protocols bgp group AS65600 family inet labeled-unicast
set protocols bgp group AS65600 peer-as 65600
set protocols bgp group AS65600 neighbor 5.5.5.2
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive

ASBR2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 5.5.5.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 6.6.6.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 10.10.10.10/32
set interfaces lo0 unit 0 family iso address 49.0000.1010.1010.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 10.10.10.10
set routing-options autonomous-system 65600
set protocols mpls interface ge-0/0/1.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 10.10.10.10
set protocols bgp group INTERNAL family inet labeled-unicast
set protocols bgp group INTERNAL neighbor 11.11.11.11
set protocols bgp group AS65400 type external
set protocols bgp group AS65400 family inet labeled-unicast
set protocols bgp group AS65400 export PE2_LOOPBACK
set protocols bgp group AS65400 peer-as 65400
set protocols bgp group AS65400 neighbor 5.5.5.1
set protocols isis source-packet-routing srgb start-label 55000
set protocols isis source-packet-routing srgb index-range 10000
set protocols isis source-packet-routing node-segment ipv4-index 1000
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set policy-options policy-statement PE2_LOOPBACK from route-filter 11.11.11.11/32 exact
set policy-options policy-statement PE2_LOOPBACK then accept

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 6.6.6.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 vlan-tagging
set interfaces ge-0/0/1 encapsulation vlan-vpls
set interfaces ge-0/0/1 unit 909 encapsulation vlan-vpls
set interfaces ge-0/0/1 unit 909 vlan-id 909
set interfaces ge-0/0/1 unit 909 family vpls
set interfaces lo0 unit 0 family inet address 11.11.11.11/32
set interfaces lo0 unit 0 family iso address 49.0000.1111.1111.0000.00
set interfaces lo0 unit 0 family mpls
set routing-options router-id 11.11.11.11
set routing-options autonomous-system 65600
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface lo0.0
set protocols bgp group INTERNAL type internal
set protocols bgp group INTERNAL local-address 11.11.11.11
set protocols bgp group INTERNAL family inet labeled-unicast resolve-vpn
set protocols bgp group INTERNAL neighbor 10.10.10.10
set protocols bgp group AS65200 multihop
set protocols bgp group AS65200 local-address 11.11.11.11
set protocols bgp group AS65200 family evpn signaling
set protocols bgp group AS65200 peer-as 65200
set protocols bgp group AS65200 neighbor 5.5.5.5
set protocols isis source-packet-routing srgb start-label 55000
set protocols isis source-packet-routing srgb index-range 10000
set protocols isis source-packet-routing node-segment ipv4-index 1100
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set routing-instances vpls instance-type evpn
set routing-instances vpls interface ge-0/0/1.909
set routing-instances vpls route-distinguisher 11.11.11.11:909
set routing-instances vpls vrf-target target:65200:909
set routing-instances vpls protocols vpls site-range 1000
set routing-instances vpls protocols vpls no-tunnel-services
set routing-instances vpls protocols vpls site vpls-1 site-identifier 1
set routing-instances vpls protocols vpls site vpls-1 interface ge-0/0/1.909
set routing-instances vpls protocols evpn interface ge-0/0/1.909

The VPLS circuit will now be up and OSPF has been configured to the 2 Cisco CE devices to confirm this.

Juniper vMX – IPv6 Tunneling over SR

3 November 20243 November 2024 nick Leave a comment

Quite a simple lab this one. A customer wants to establish IPv6 connectivity between 2 sites over our SR IPv4 core so IPv6 tunneling is required. 2 Cisco vIOS routers used as the CE devices.

https://www.juniper.net/documentation/us/en/software/junos/mpls/topics/topic-map/ipv6-o-ipv4-tunnels.html

_Exports_eve-ng_export-20241103-120152 Download

PE1

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.1/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family inet6
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet6 address 2a45:0425:2ca1::0567:5673:23b4/127
set interfaces lo0 unit 0 family inet address 5.5.5.5/32
set interfaces lo0 unit 0 family iso address 49.0000.5555.0000.0000.00
set interfaces lo0 unit 0 family mpls
set policy-options policy-statement BGPv6 from family inet6
set policy-options policy-statement BGPv6 from protocol bgp
set policy-options policy-statement BGPv6 then accept
set policy-options policy-statement V6 from family inet6
set policy-options policy-statement V6 from protocol bgp
set policy-options policy-statement V6 from protocol direct
set policy-options policy-statement V6 then accept
set policy-options policy-statement next-hop-self then next-hop self
set routing-options router-id 5.5.5.5
set routing-options autonomous-system 65400
set protocols bgp group CE1 type external
set protocols bgp group CE1 local-address 2a45:0425:2ca1::0567:5673:23b4
set protocols bgp group CE1 family inet6 unicast
set protocols bgp group CE1 export BGPv6
set protocols bgp group CE1 peer-as 65001
set protocols bgp group CE1 neighbor 2a45:0425:2ca1::0567:5673:23b5
set protocols bgp group V6TUNNEL type internal
set protocols bgp group V6TUNNEL local-address 5.5.5.5
set protocols bgp group V6TUNNEL family inet6 labeled-unicast explicit-null
set protocols bgp group V6TUNNEL export next-hop-self
set protocols bgp group V6TUNNEL export V6
set protocols bgp group V6TUNNEL neighbor 7.7.7.7
set protocols isis source-packet-routing srgb start-label 30000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 100
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols mpls ipv6-tunneling
set protocols mpls interface ge-0/0/0.0

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family inet6
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet address 2.1.1.1/30
set interfaces ge-0/0/1 unit 0 family iso
set interfaces ge-0/0/1 unit 0 family inet6
set interfaces ge-0/0/1 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 6.6.6.6/32
set interfaces lo0 unit 0 family iso address 49.0000.6666.0000.0000.00
set routing-options router-id 6.6.6.6
set routing-options autonomous-system 65400
set protocols isis source-packet-routing srgb start-label 30000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 200
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface ge-0/0/1.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols mpls interface ge-0/0/0.0
set protocols mpls interface ge-0/0/1.0

PE2

set chassis network-services enhanced-ip
set interfaces ge-0/0/0 unit 0 family inet address 2.1.1.2/30
set interfaces ge-0/0/0 unit 0 family iso
set interfaces ge-0/0/0 unit 0 family inet6
set interfaces ge-0/0/0 unit 0 family mpls
set interfaces ge-0/0/1 unit 0 family inet6 address 2ab5:0425:2ca1::0567:5673:23b4/127
set interfaces lo0 unit 0 family inet address 7.7.7.7/32
set interfaces lo0 unit 0 family iso address 49.0000.7777.0000.0000.00
set interfaces lo0 unit 0 family mpls
set policy-options policy-statement BGPv6 from family inet6
set policy-options policy-statement BGPv6 from protocol bgp
set policy-options policy-statement BGPv6 then accept
set policy-options policy-statement V6 from family inet6
set policy-options policy-statement V6 from protocol bgp
set policy-options policy-statement V6 from protocol direct
set policy-options policy-statement V6 then accept
set policy-options policy-statement next-hop-self then next-hop self
set routing-options router-id 7.7.7.7
set routing-options autonomous-system 65400
set protocols bgp group CE1 type external
set protocols bgp group CE1 local-address 2ab5:0425:2ca1::0567:5673:23b4
set protocols bgp group CE1 family inet6 unicast
set protocols bgp group CE1 export BGPv6
set protocols bgp group CE1 peer-as 65003
set protocols bgp group CE1 neighbor 2ab5:0425:2ca1::0567:5673:23b5
set protocols bgp group V6TUNNEL type internal
set protocols bgp group V6TUNNEL local-address 7.7.7.7
set protocols bgp group V6TUNNEL family inet6 labeled-unicast explicit-null
set protocols bgp group V6TUNNEL export next-hop-self
set protocols bgp group V6TUNNEL export V6
set protocols bgp group V6TUNNEL neighbor 5.5.5.5
set protocols isis source-packet-routing srgb start-label 30000
set protocols isis source-packet-routing srgb index-range 1000
set protocols isis source-packet-routing node-segment ipv4-index 300
set protocols isis level 1 disable
set protocols isis level 2 wide-metrics-only
set protocols isis interface ge-0/0/0.0 point-to-point
set protocols isis interface lo0.0 passive
set protocols mpls ipv6-tunneling
set protocols mpls interface ge-0/0/0.0

Routes are now being learned from the other CE device and IPv6 connectivity is up between the 2 sites.
